Excellent Quality Wire Braid Hydraulic Hose

Send Inquiry

Request To Call Back

Excellent Quality Wire Braid Hydraulic Hose

Get a Price/Quote

MOQ : 50 Meters

Excellent Quality Wire Braid Hydraulic Hose Specification

Tolerance
0.5 mm Millimeter (mm)

Feature
Flexible, durable, abrasion & weather resistant

Usage & Applications
Hydraulic systems, construction machinery, industrial equipment, high-pressure fluid transfer

Product Type
Wire Braid Hydraulic Hose

Thickness
3 mm to 8 mm Millimeter (mm)

Diameter
6.4 mm to 50.8 mm (internal diameter) Millimeter (mm)

Resistance level
High pressure, oil, abrasion, and weather resistance

Water Absorption
Low

Surface Finish
Smooth or wrapped (as required)

Hardness
70-90 Shore A

Material
Synthetic rubber with high-tensile steel wire braid

Components
Inner tube, wire braid reinforcement, outer cover

Color
Black

Rubber Type
Nitrile, EPDM, or blend

Flame Resistance Level
Meets industry standard flame resistance

Natural Rubber
Blended with synthetic rubber (Nitrile/EPDM options)

Style
Reinforced braided

Tensile Strength
180-350 MPa Megapascals (MPa )

Weight
Depends on size and length; approx. 0.152.50 kg/m Kilograms (kg)

Part Type
Hose

Size
1/4 inch to 2 inch (customized available)

Length
Up to 100 meters (custom length available) Meter (m)

Temperature Resistance
-40C to +100C (intermittently up to 120C)

Density
1.35 Gram per cubic centimeter(g/cm3)

Marking
Continuous inkjet marking with specifications/branding

Minimum Bend Radius
As per SAE/EN specifications; varies by size

Cover Material
Synthetic abrasion and weather resistant rubber

Inner Tube Material
Oil-resistant synthetic rubber

Reinforcement Type
Single or double high-tensile steel wire braid

Compatibility
Suitable for hydraulic fluids: mineral oils, glycol, polyglycol, vegetable & hydraulic oils, and water emulsions

Excellent Quality Wire Braid Hydraulic Hose Trade Information

Minimum Order Quantity
50 Meters

Supply Ability
Meter

Delivery Time
1 Week

About Excellent Quality Wire Braid Hydraulic Hose

Wire Braid Hydraulic Hose

CONSTRUCTION:

Tube: Hydraulic Oil Resistant Special synthetic rubber.
Reinforcement: One synthetic textile braids wire braid.
Cover: Abrasion, Ozone & weather resistant synthetic rubber.
Temperature Range: Medium From -40°C up to+100°C

APPLICATIONS: Hose range suitable to carry hydraulic fluids such as glycol, mineral oils fuels, lubrication, emulsion, hydrocarbons etc.

Specification

Hose ID		Wire OD	Hose OD	Working Pressure		Burst Pressure		Minimum Bend Radius	Weight
Inch	mm	mm	mm	BAR	Psi	BAR	Psi	mm	Kg/m
5	3/16	4.8	11.1	34	500	138	2000	50	0.11
6	1/4	6.4	12.4	28	400	110	1600	65	0.15
8	5/16	7.9	14.3	28	400	110	1600	75	0.16
10	3/8	9.5	15.9	28	400	110	1600	75	0.18
13	1/2	12.7	19.8	28	400	110	1600	100	0.26
16	5/8	15.9	23.0	24	350	97	1400	125	0.29
19	3/4	19.0	26.6	21	300	83	1200	150	0.40

Flexible & Durable Hydraulic Solution

Designed for high-pressure and heavy-duty usage, these wire braid hydraulic hoses provide flexibility and resilience. The synthetic rubber materials ensure minimal water absorption, high oil and abrasion resistance, and robust performance in challenging environments. Customizable sizes and finishes make them suitable for many applications.

Industry-Compliant Performance

These hoses comply with SAE/EN specifications for minimum bend radius and temperature resistance. Their flame-resistant covers meet industry safety standards, safeguarding against fire hazards in workplaces. With low thermal conductivity and standardized density, the hoses are reliable for consistent hydraulic operations.

Versatile Application Range

Wire braid hydraulic hoses are used in hydraulic systems, construction machinery, and industrial equipment, supporting high-pressure fluid transfers. Compatible with mineral oils, water emulsions, and synthetics, they are a preferred choice for distributors, exporters, manufacturers, and suppliers across India.

FAQs of Wire Braid Hydraulic Hose:

Q: How is the wire braid hydraulic hose constructed for enhanced durability?

A: The hose features a single or double layer of high-tensile steel wire braid reinforcement, bonded between an oil-resistant synthetic rubber inner tube and an abrasion-resistant synthetic rubber cover. This structure delivers excellent resistance to pressure, abrasion, weather, and various hydraulic fluids.

Q: What is the minimum burst pressure of the wire braid hydraulic hose?

A: The burst pressure of the hose is at least four times the designated working pressure, ensuring a high level of safety and reliability for demanding hydraulic applications.

Q: When should I select a single or double wire braid hydraulic hose?

A: Single wire braid hoses are typically chosen for moderate pressure requirements and flexibility, while double wire braid hoses are preferred for higher pressures and improved tensile strength in more rigorous hydraulic conditions.

Q: Where can these hydraulic hoses be used most effectively?

A: They are ideal for hydraulic systems in construction machinery, industrial equipment, and any application requiring high-pressure fluid conveyance and robust abrasion resistance, including export, distribution, and manufacturing sectors.

Q: What hydraulic fluids are compatible with these hoses?

A: The hoses support mineral oils, glycol, polyglycol, vegetable and hydraulic oils, and water emulsionsmaking them versatile for varied hydraulic system requirements.

Q: How does the hose marking process work?

A: Continuous inkjet marking is used to print specifications and branding along the hose length, ensuring traceability and easy identification during installation or maintenance.

Q: What are the key benefits of using wire braid hydraulic hoses from this supplier?

A: Users benefit from hoses engineered for high flexibility, exceptional durability, abrasion and oil resistance, customizable sizes and finishes, reliable flame resistance, and compliance with SAE/EN standards.
